Sedwall Manufacturing Company

2 – MOORE #450CP CNC JIG GRINDER, CONTINUOUS PATH 5-AXIS
1 - MOORE #8400CP CNC JIG GRINDER,
CONTINUOUS PATH 5-AXIS
2 - MOORE #G18 JIG GRINDERS (CONVENTIONAL)
2 - JIG BORERS

1 – 30” X 80” MATTISON SURFACE GRINDER
3 - 12 X 36 GALLMEYER LIVINGSTON; EQUIPPED W/
INCREMATIC FEED & CRUSH GRINDING ATTACHMENT
1 – ELB-SCHLIFF 24” HORIZONTAL SPINDLE
ROTARY SURFACE GRINDER
1 – 8 X 18 MITSUI AUTOMATIC SURFACE GRINDER
2 - 6 X 18 NORTON SURFACE GRINDER
1 – 6 X 12 MITUSI HANDFEED SURFACE GRINDER
5 - 6 X 12 BOYER SCHULTZ SURFACE GRINDERS

3 - 60” DIAMETER VERTICAL INTERNAL
    & EXTERNAL GRINDER W/ DIGITAL READOUT
1 – KELLENBERGER – CNC OD-ID GRINDER
     10” DIA. X 40” LENGTH CAPACITY
1 - 18” DIAMETER X 72” LONG CINCINNATI
     W/ INTERNAL ATTACHMENT
1 - 12” DIAMETER X 36” LONG CINCINNATI
1 - JONES & SHIPMAN MODEL 1307 EIT 14” DIA. X 40”
5 - 12” DIAMETER X 36” LONG GALLMEYER AND LIVINGSTON
     INTEGRAL INTERNAL SPINDLE &
     CRUSH GRINDING ATTACHMENT
1 - 6 X 12 MYFORD GRINDER I.D. & O.D.
1 - SHEFFIELD OPTICAL GRINDER

1 – MORI SEIKI 2500/700 CNC TURNING CENTER
1 – MORI SEIKI SL204 CNC TURNING CENTER
2 - ST-16/22V CNC VERTICAL TURRET LATHE 87" SWING X 30"
HEIGHT
1 - KING 48” VERTICAL TURRET LATHE
1 - LODGE & SHIPLEY 17” DIAMETER SWING X 36” CENTERS
1 - 24” X 72” MONARCH LATHE
1 – 15” x 50” CLAUSING/COLCHESTER “VS” LATHE

1 - OKUMA & HOWA 7VA, 30 X 60 TRAVEL
     VERTICAL MACHINING CENTER
1 - MATSUURA MC-760 VERTICAL MACHINING CENTER;
    30 POSITION TOOL CHANGER
1 - HAMAI 3VA VERTICAL MACHINING CENTER
1 - HURCO VERTICAL MACHINING CENTER
6 - BRIDGEPORTS W/OPTICS AND DIGITAL READOUT;
    (2) EQUIPPED WITH 2 AXIS CNC

1 - GIDDINGS & LEWIS 4” BORING MILL; 4’ X 6’ TABLE
W/ DIGITAL READOUT
1 - KEARNEY & TRECKER W/ 12” X 50” TABLE
1 - KEARNEY & TRECKER W/ 12” X 60” TABLE

1 - CARLTON RADIAL DRILL 4’ X 11”
1 - HERCULES RADIAL DRILL PRESS
3’ ARM X 8” COLUMN
1 - CLAUSING 20” DRILL PRESS
VARIOUS SINGLE SPINDLE DRILL PRESSES,
PLUS TAPPING ATTACHMENTS

1 - BROWN & SHARPE MicroXcel
    COORDINATE MEASURING MACHINE
2 - JONES & LAMSON 14” OPTICAL COMPARATOR
    W/ PROFILE TRACING ATTACHMENT
1 - SCHERR-TUMICO MICRO SURFACE
    ILLUMINATOR OPTICAL COMPARATOR
1 - “WILSON” HARDNESS TESTER
1 - BROWN & SHARPE ELECTRONIC SURFACE
    MEASURING SYSTEM
1 - BROWN & SHARPE 12” HEIGHT MICROMETER
    (W/DIGITAL READOUT)
16 - 300P .001 DIAL CARBIDE O.D. SNAP GAGES - 0 - 12”
1 - EX-CELLO 30” OPTICAL COMPARATOR
1 - SUNNEN HOLE GAGING SYSTEM
1 - BENDIX PROFILOMETER

1 - AGIE 270SF HSS WIRE EDM MACHINE - FULLY
     SUBMERSIBLE SELF THREADING
1 – AGIE DEM400 WIRE EDM MACHINE
1 - OLIVER DRILL POINTER
AUTOCAD 2009 COMPUTER ASSISTED DESIGNING SYSTEM
2 - EDGECAM BY PATHTRACE
    COMPUTER ASSISTED
    DESIGNING/MACHINING (CAD/ CAM) SYSTEM
1 – ESPRIT COMPUTER ASSISTED MACHINING SYSTEM
1 - INGERSOLL #200B
    ELECTRICAL DISCHARGE MACHINE (EDM)
    POWER SPINDLE ROTATION,
    SWIVELING HEAD TO 45°
    W/ 42” 22” WORK AREA. (W/ DIGITAL READOUT)
ARC WELDING EQUIPMENT
1 - HYDRAULIC ROLL MARKING MACHINE
1 - ELECTRO CHEMICAL MARKING MACHINE
1 - GROB VERTICAL BAND SAW
1 - JOHNSON HORIZONTAL POWER SAW
1 - GROB BAND FILING MACHINE
1 - PRATT & WHITNEY DIAFORM
2 - SHAUER SPEED LATHE
1 - HUPPERT ELECTRIC HEAT TREATING FURNACE
2 - J & S RADII DRESSERS
2 - CLEARVIEW WHEEL DRESSER
3 - LAST WORD DIAMOND RADIUS DRESSER
1 - MORRISON KEYSEATER
1 - WELLS AUTOMATIC POWER CUTOFF SAW
1 - SUNNEN HONE
1 - UNI-HONE DRY BLAST
1 - UNIVERSAL ABRASIVE BLAST CABINET
1 - CRANE FLAT LAPPING MACHINE
1 - SPITFIRE CYLINDRICAL LAPPING MACHINE
ACETYLENE WELDING & BRAZING EQUIPMENT
